Different Types of Titanium Alloys

Titanium alloys are engineering materials noted for their high strength, low weight, and good corrosion resistance.

By alloying titanium with various elements, these alloys can be developed to meet the specific performance requirements of different industries.

This article gives an in-depth view of classifications of titanium alloys, their mechanical, physical, and thermal properties, industries where they are found, and machining and heat treatment considerations.

Alpha alloys are single-phase materials with an HCP crystal structure stabilized by chemical elements like aluminum, oxygen, nitrogen, and carbon. These alloys provide moderate strength, are highly corrosion-resistant, and perform well at high temperatures.

They can't be heat-treated due to their single-phase structure, restricting precipitation hardening.

Alpha-stabilizing chemical elements, instead, favor high strength via solid solution strengthening, but excessive alloying (such as aluminum equivalence above 9%) might precipitate brittle intermetallics. The alloys provide fracture toughness and creep resistance in aggressive environments.

Apply for Free Sample

Near-alpha titanium alloys are composed mainly of the alpha phase with 1–2% of beta-stabilizing chemical elements such as molybdenum or silicon, which introduces a small amount of ductile beta alloy phase.

These alloys retain the alpha alloys' corrosion resistance and fracture toughness while improving hot workability and possessing limited heat treatability.

Their microstructure, basically alpha with minor beta particles along the grain boundaries, exhibits creep resistance at elevated temperatures, thus making them useful for some applications.

Alpha-beta alloys have two phases in the microstructure and consist of mixtures of both alpha and beta phases through the addition of alpha-stabilizing chemical elements, such as aluminum, and beta-stabilizing chemical elements, such as vanadium and molybdenum.

These alloys are heat treatable and can significantly increase in high strength through quenching and aging. Compared with alpha and near alpha alloys, the beta phase provides good formability, fatigue resistance, and less creep resistance.

The alpha-beta alloy Ti-6Al-4V has balanced mechanical properties and uses about 50% of titanium alloying.

Beta titanium alloys have a BCC structure stabilized by a high concentration of beta-stabilizing elements such as molybdenum, vanadium, or iron. These alloys are heat treatable and can reach very high strengths through precipitation of fine alpha particles during aging.

Beta alloys present good cold formability and good fracture resistance, yet they provide lowered ductility and fatigue resistance when heat-treated

Metastable beta alloys with molybdenum equivalent 10-30, after rapid cooling, remain fully beta and can provide high strength for the most demanding applications.

Ti-6Al-4V (or ASTM Grade 5) is a highly used titanium alloy comprising approximately 6% aluminum and 4% vanadium, with minor amounts of carbon, nitrogen, and hydrogen.

It is an alpha-beta alloy that develops tensile strengths in the range of 895-1100 MPa, is atmospherically corrosion resistant, and has a very good strength-to-weight ratio, making it preferred in aerospace and biomedical materials.

The heat-treatment processes can provide desired mechanical and physical properties, with solution treatment and aging in balance, promoting high strength while maintaining good ductility.

The near-alpha combo, Ti-6242, has been developed at elevated temperatures. It contains 6% aluminum, 2% tin, 4% zirconium, and 2% molybdenum, which gives it superior creep resistance to sustain high strength at elevated temperatures up to 550°C.

Its microstructure supports resistance to corrosion and thermal stability, thus being fit for jet engines and other high-temperature aerospace components.

Mechanical Properties

The mechanical properties of titanium alloys are critical for load-bearing applications. Based on MatWeb data, the table below details tensile strength, yield strength, elongation, and hardness for key titanium grades.

It contains medium-strength and high-ductility commercial pure titanium grades, iofwhich Grade 4 is the strongest among commercial pure grades. Alpha and near-alpha alloys, like Ti-6242, provide medium strength and high fracture toughness.

Alpha-beta types such as Ti-6Al-4V afford high strength and fatigue resistance. In contrast, high-temperature beta alloys, such as Beta C, can develop above 1200 MPa, being appropriate for high-stress applications but having limited ductility.

Physical Properties

Physical properties influence an alloy's suitability for applications requiring specific weight or magnetic characteristics. The table below, sourced from MatWeb, details density and specific gravity.

Titanium alloys with a density ranging from 4.4 to 4.8 g/cm³ are much lighter than other metals like steel (7.9 g/cm³), which accounts for their light weight and great strength. Titanium alloys are good options where low magnetic interference is needed, such as for medical and aerospace requirements.

Electrical Properties

Titanium alloys have high electrical resistivity (0.42-1.78 μΩ·m) compared to other metals like copper (0.017 μΩ·m), so they have lower conductivity.

The property can be an electrically insulating material in setups where corrosion resistance and non-conductivity are most desired, such as in chemical processing equipment.

Thermal Properties

Thermal properties are critical for applications involving high temperatures. The table below, details thermal conductivity and maximum service temperature.

Titanium alloys shipped with low thermal conductivity make them difficult to machine but acceptable throughout high temperatures.

Due to phase stability, commercially pure titanium is limited to 350°C, while alloys such as Ti-6Al-4V and Ti-6242 go through extreme temperatures of 400–550°C, respectively.
