Astm B348 Titanium Pipe Welding
Scope of application: The standard covers annealed or solution-treated titanium and titanium alloy bars, rods and wires, including welded titanium tubing.
Description
Mechanical Properties
Tensile Strength: Tensile strength varies depending on the alloy grade. For example, Grade 2 tensile strengths typically range from 240 MPa to 370 MPa, while Grade 5 tensile strengths typically range from 830 MPa to 950 MPa.
Yield Strength: Again, this varies by alloy grade. For example, the yield strength of Grade 2 typically ranges from 170 MPa to 240 MPa, while the yield strength of Grade 5 typically ranges from 780 MPa to 870 MPa.
Elongation: ≥ 10% (for Grade 5), ≥ 20% (for Grade 2).
Industry-leading Astm B348 titanium tubing production technology
|
Name
|
Titanium Tube & Pipe
|
|||
|
Standard
|
ASTM B338/ASME SB338, ASTM B337/ASME SB337, ASTM B861/ASME SB861, ASTM B862/ASME SB862,AMS4911,AMS4928
|
|||
|
Material Grade
|
Gr1, Gr2, Gr4, Gr7, Gr9, Gr11, Gr12, etc
|
|||
|
Length
|
≤14000mm
|
|||
|
Size(mm)
|
Diameter 3-508mm
|
|||
|
Section shape
|
Round / Square
|
|||
|
Tolerance
|
a) Outer Diameter: +/- 0.01mm
b) Thickness: +/- 0.01mm c) Length: +/- 0.1mm |
|||
|
Surface
|
Pickling, annealing, polishing, bright.
|
|||
|
Feature
|
1.Low Density and High Strength
2.Excellent Corrosion Resistance 3.Good resistance to effect of heat 4.Excellent Bearing to cryogenic property 5.Nonmagnetic and Non-toxic 6.Good thermal properties 7.Low Modulus of Elasticity |
|||
|
Test
|
Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
|
|||
Areas of application
Aerospace: for the manufacture of aircraft structural components, engine parts and hydraulic systems.
Medical industry: for the manufacture of orthopedic implants, dental implants and medical devices.
Chemical industry: for heat exchangers, reactors and other equipment requiring corrosion resistance.
Packaging of Astm B348 welded titanium tubing
Supply of Astm B348 titanium round tubes by professionally recognized team
The company has obtained iso9001:2015 quality management system certification, iso14001:2015 environmental management system certification, ISO 45001:2018 occupational health and safety management system certification, PED 2014/68/EU Pressure Equipment Directive certification, DNV-GL material manufacturer certification, SGS product quality certification and other certificates and qualifications. We strictly implement GB/T 3639-2009, ASTM A519, DIN2391, JIS G3445 and other national and international standards to ensure the quality of our products.
