Titanium Seamless Piping Grade 1
Grade 1 seamless titanium piping (ASTM B861/ASME SB861): the softest, most formable CP grade - composition O 0.18 max, outstanding corrosion resistance, weldability and biocompatibility for chemical, medical and marine service.
Description
What Grade 1 Seamless Titanium Piping Is
Grade 1 is the first and softest of the four commercially pure (CP) titanium grades. It offers maximum formability, excellent corrosion resistance and high impact toughness - the reference choice wherever easy forming is required, supplied as seamless pipe and tube.
Chemical Composition (ASTM B861, wt % max)
| O | N | C | H | Fe | Each other | Total | Ti |
|---|---|---|---|---|---|---|---|
| 0.18 | 0.03 | 0.08 | 0.015 | 0.20 | 0.1 | 0.4 | Balance |
Oxygen is the main strengthening element in CP titanium; Grade 1's low oxygen ceiling keeps it soft and formable.
Standards and Range (Corrected)
ASTM B861 (seamless pipe), B338 (heat exchanger tube), B862 (welded pipe); ASME SB861/SB338/SB862.
Tubes range: 1 mm OD to 254 mm OD; wall 0.1-20 mm.
Key Properties
Corrosion resistance: outstanding in chlorides, sulfuric acid, nitric acid and many alkaline media; in strong-alkali service its resistance can exceed that of stainless steel (environment-dependent).
Weldability: excellent - welds to other titanium materials with strong, sealed joints.
Toughness and ductility: bends, flares and expands without cracking.
Biocompatibility: suitable for medical devices.
Strength: moderate - it is the softest CP grade; select Grade 2 or 3 for higher strength.
First-class titanium production technolog
Applications
Aerospace: structural components such as wing beams and fuselage frames for weight saving. Note: compressor blades are a titanium-alloy application, not CP Grade 1 - Grade 1 suits non-turbine structural and ducting parts.
Chemical: reactors, heat exchangers, pipelines, seawater desalination equipment.
Medical: implants, fracture fixation devices, surgical instruments, medical pipelines.
Electronics: semiconductor gas lines and reaction chambers where purity and corrosion resistance are critical.
Architecture: facade decoration, high-end building water supply and drainage systems.
Fabrication Notes
Welding: full inert-gas shielding on both sides, clean surfaces, low heat input; titanium embrittles if contaminated above ~400°C.
Severe forming: use the annealed condition.
Supply: batch test certificates (composition and mechanicals) per heat.
