Why Does Deformation Occur During the Processing of Titanium Alloy Components?
Sep 10, 2025
Products Description
CNC Titanium Alloy Seals For Deep-sea
CNC High-performance Engine Crankshafts
CNC Metal Parts For The New Energy Industry
Titanium alloy components are prone to deformation during processing, primarily due to the physical properties of titanium alloys and certain factors in the machining process. The following suggestions address deformation issues during the processing of titanium alloy components:
① Control Processing Temperature: Titanium alloys have a higher thermal expansion coefficient than most metals, making them susceptible to deformation when processing temperatures change. Therefore, during processing, the temperature should be appropriately increased to enhance material plasticity, reduce material hardness and internal stress, and minimize cutting heat. However, temperatures should not be excessively high, as this can lead to material oxidation and tool adhesion. Generally, the processing temperature should be controlled around 550°C.
② Optimize Cutting Parameters: When cutting titanium alloys, suitable tools and cutting parameters should be selected based on specific conditions. High-speed tungsten steel tools are recommended, and cutting depth and speed should be reasonably controlled. The cutting depth should not exceed 50% of the tool diameter to reduce friction between the titanium alloy and the tool, as well as cutting heat.
③ Reduce Machining Stress: Titanium alloys generate significant strain and machining stress during processing, which can affect material plasticity and strength, leading to deformation. Therefore, machining stress should be minimized. For example, use step-by-step machining, apply sufficient clamping force, and adjust clamping force to reduce deformation caused by fixture setup.
④ Control Material Quality: Titanium alloys often contain internal impurities that can affect material properties during processing. Thus, titanium alloy materials should undergo strict inspection and control before processing to ensure they meet machining requirements.
⑤ Use Suitable Machining Methods: Machining methods for titanium alloys include mechanical processing, chemical processing, electrical discharge machining, and laser processing. The appropriate method should be selected based on specific conditions, and corresponding measures should be taken to reduce deformation during processing.
⑥ Enhance Clamping and Support: During processing, auxiliary support should be provided for areas corresponding to clamping positions. Using large-area soft support can reduce part vibration tendencies while applying minimal and uniform support force. This leverages the part's local rigidity to counteract deformation caused by machining forces.
⑦ Pay Attention to Tool Sharpness: Insufficient tool sharpness can lead to uneven machining forces, causing deformation. Therefore, tool sharpness should be regularly checked during processing to ensure tools remain sharp and maintain good cutting performance.
Titanium product forms available from GNEE
|
Item Name |
china wholesale stock astm b337 b338 gr1 gr2 gr9 titanium pipe titanium tubes seamless |
|||
|
Material |
pure titanium and titanium alloy |
|||
|
Standard |
ASTM B337, ASTM B338. ASTM B861, ASTM B862 |
|||
|
Brand |
China Grades: TA1, TA2, TC4 (Gr5 Equivalent), TA9 (Gr7 Equivalent), TA10 (Gr9 Equivalent), TA18 |
|||
|
Shape |
Round Titanium Tube/Pipe, Square Titanium Tube/Pipe, Rectangular Titanium Tube/Pipe, Titanium Coil Tube |
|||
|
Type |
Seamless & Welded (ASTM B337/B338 for Industrial & Heat Exchanger Applications) |
|||
|
Product name |
Pure Titanium bar/Pure Titanium rod/Titanium alloy bar/Tianium alloy rod |
|
Standard |
GB/T 2965-2007 GB/T 13810-2007, ASTM B348,ASTM F67,ASTM F136, AMS4928,MIL4911 |
|
Titanium type |
Commercially Pure(CP) / Titanium alloy |
|
Grade |
TA1 TA2 TA3 TA4 TA5 TA6 TA7 TA8 TA9 TA10 TA11 TA12 TA13 TA14 |
|
Diameter |
3-350mm |
|
Length |
Max6000mm |
|
Technique |
Forging, machining |
|
Surface |
Acid surface or polishing, sand blasted surface |
|
Shape |
Round, flat, square, hexagonal |
|
Application |
Metallurgy, electronics, medical, chemical, petroleum, pharmaceutical, aerospace, etc. |
|
Production Name |
Titanium plate/Titanium sheet |
|||
|
Grade |
Gr1, Gr2, Gr3,Gr4,Gr5, Gr7, Gr6,Gr9, Gr11, Gr12 ,Gr16, Gr17,Gr25 |
|||
|
Size |
All sizes can be customized |
|||
|
Application |
Metallurgy, electronics, machinery, medical treatment, chemical industry, petroleum, medical treatment, aerospace |
|||
|
Feature |
High corrosion resistance, low density, good thermal stability |
|||
|
Technology |
Hot Forged, Hot Rolled, Cold Rolled, Annealing, Pickling |
|||
|
Surface |
Bright, Polished, Pickling, Acid cleaning, Sandblasting |
|||
|
Packing |
Export Standard Woodcase |
|||
|
Delivery time |
10-25days according to the quantity and process of the product |
|||
|
Quality and test |
Hardness test, Bending test, Hydrostatic etc. |
|||
|
Product name |
Titanium wire |
|
Grade |
GR1,GR2,GR3,GR4,GR5,GR7,GR9,GR11,GR12,GR23 etc.
ERTi-1, ERTi-2, ERTi-3, ERTi-4, ERTi-5, ERTi-7, ERTi-9, ERTi-11, ERTi-12 |
|
Size |
Dia：0.1-8mm or customizable |
|
Standard |
ASTM B348,ASME SB348,ASTM B863,AWS.A5.16,GB/T3623-2007 |
|
MOQ |
10kg |
|
Quality and test |
Annealing, Ultrasonic testing |
|
Application |
Aerospace, Chemical, Medical, Eye Frames,Welding etc |
|
Feature |
High strength,Light weight,Excellent heat conduction and corrosion resistance |
|
Condition |
Annealed (M), Hot Worked (R), Cold Worked (Y) |
|
Surface |
Bright, Polished, Pickling, Sandblasting |
|
Package |
Wooden Box |
|
Product Name
|
Custom Precision CNC Machining Services
|
|
Material
|
Metal: Aluminum, Stainless Steel, Copper, Iron, Titanium Alloy, Zinc Alloy, Magnesium Alloy.
Plastic: Nylon, ABS, POM, PC, PP, PE, PETG, PEEK, PMMA, PVC, UHMW.
|
|
Surface treatment
|
Anodizing, Polishing, Electroplating, Powder Coating, Sandblasting, Magnetic Polishing, Spray Painting, Drawing, Embossing, Electrophoresis, Screen Printing, Laser Engraving.
|
|
Process
|
3-Axis/4-Axis/5-Axis/6-Axis CNC Milling, CNC Turning
|
|
Application
|
Mechanical Spare Parts, Aerospace Components, Automotive Parts, Maintenance Parts
|
|
Maximal Part Size
|
3000 mm (118 in)
|
|
Minimal Part Size
|
2 mm (0.08 in)
|
|
Drawing format
|
DWG, DXF, PDF, SOLIDWORKS, PRT, STP, STEP, IGS, etc.
|
|
Certification
|
ISO 9001:2015
|
GNEE is a specialized manufacturer and exporter of high-quality titanium products, including pipes, sheets, bars, wires, and fabricated parts.
We utilize advanced CNC machining, rolling, and welding equipment to ensure precision manufacturing. All products undergo strict chemical, mechanical, and non-destructive testing to guarantee compliance with international standards.
Our export-safe packaging includes wooden crates and waterproof wrapping to ensure secure delivery. If you have any needs, please feel free to contact us immediately：info@gneemetal.com
