Solid Titanium Rod
Titanium rods and round bars are a very popular go-to for many products. These require a much more automated process to make than plate and block, which still involve a manual process. Typically manufactured in 8-12 ft. lengths and can be easily cut to custom sizes and shipped.
Description
Our standard titanium rod sizes range from 1/8" x 1/8" to 1/4" x 1/4" with a diameter of 3 mm. We can also provide titanium rods outside this range and deposition materials for specific applications (e.g., fuel cells and solar) and for thin film deposition on glass or metal substrates.
Products Description
GNEE specializes in the production of high purity titanium rod, uniformly shaped titanium rods with the highest possible density of 99.9+% ultra-high purity metal rods and the smallest possible average grain size for use in semiconductor, Chemical Vapor Deposition (CVD), and Physical Vapor Deposition (PVD) processes, including Hot Beam and E-Beam (E-Beam) evaporation, Low Temperature Organic Evaporation (LTOE), Atomic Layer Deposition (ALD), Metallic Organic and Chemical Vapor Deposition (MOCVD). chemical vapor deposition (MOCVD).
First-class titanium production technology
Titanium Rod Properties (Theoretical)
| Molecular Weight | 47.86 (Note: all properties listed are for bulk titanium metal) |
|---|---|
| Appearance | Silvery |
| Melting Point | 1668 °C |
| Boiling Point | 3560 °C |
| Density | 4.54 g/cm3 |
| Solubility in H2O | N/A |
| Crystal Phase / Structure | Hexagonal |
| Electrical Resistivity | 42.0 microhm-cm @ 20 °C |
| Electronegativity | 1.45 Paulings |
| Heat of Fusion | 14.15 kJ/mol |
| Heat of Vaporization | 425 kJ/mol |
| Poisson's Ratio | 0.32 |
| Specific Heat | 0.125 Cal/g/K @ 25 °C |
| Tensile Strength | 140 MPa |
| Thermal Conductivity | 21.9 W/(m·K) @ 298.2 K |
| Thermal Expansion | 8.6 µm·m-1·K-1 (25 °C) |
| Vickers Hardness | 830–3420 MPa |
| Young's Modulus | 116 GPa |
