SA387 GR 11 CLASS 2 Molybdenum Alloy Plate
As a pressure vessel grade steel for use in high temperature environments, it can be used in a variety of industries and is very effective, especially in the oil, gas and petrochemical industries where liquids and gases are typically stored at higher temperatures.
Description
ASME SA387 Grade 11 Class 2 is Chrom-Moly steel plate used for welding boilers and pressure vessles designed for high temperature serivce, nominal chrome content at 1.00% to 1.50%, and Moly 0.45% to 0.65% for SA387 GRADE 11 material.
Products Description
Refered Standards for ASTM A387 Alloy Steel Plate
ASTM
A20/A20M: General requirements for pressure vessel plates.
A370: Test specification for mechanical properties of steel
A435/A435M: For straight-beam ultrasonic examination of steel plates
A577/A577M: For ultrasonic angle beam examination of steel plates
A578/A578M: For straight beam UT examination of rolled steel plates in special applications
A1017/A1017M: Specification for pressure vessle plates of alloy steel, chromium-molybdenum-tungsten
Professional Metal Suppliers - GNEE
Equivalents
| BS | EN | ASTM/ASME | DIN |
| 621 B | ––– | SA387-11-2 | ––– |
Specifications for ASME SA387 Grade 11 Alloy Steel Plates
Chromium & Molybdenum content (according to the ASME specification)
| Designation | Nominal Chromium Content (%) |
Nominal Molybdenum Content (%) |
| SA387 Grade 11 | 1.25% | 0.50% |
Tensile Requirements for ASME SA387 Grade 11 Alloy Steel Plates Class 2 Plates
| Designation: | Requirement: | Grade 11 |
| SA387 Grade 11 | Tensile strength, ksi [MPa] | 75 to 100 [515 to 690] |
| Yield strength, min, ksi [MPa]/(0.2% offset) | 43 [310] | |
| Elongation in 8 in. [200mm], min % | 18 | |
| Elongation in 2 in. [50mm], min, % | 22 | |
| Reduction of area, min % | ––– |
Large-scale factory production
FAQ
Q: What length of pipe do you provide?
A: We can produce pipes of any length according to customer's requirements.
Q: What's the MOQ for your products?
A: We have no minimum order quantity. We can fulfill any order, no matter how big or small it is.
Q: Do you offer customized solutions?
A: Yes, we provide customized solutions according to the specific needs of our customers.
Q: How long is the lead time for your products?
A: Delivery time depends on order quantity and customization requirements. We always aim to deliver as soon as possible.
What are the quality standards of your products?
A: Our products comply with ASTM, AISI, JIS and other international quality standards to ensure that our customers get the highest quality products.
